New UXP 2U 4Node 24Bay Server 1YR Warranty
Product Code:
226704-UXP-2U4N-24BS-SATA-V3-2PS NEW
Availability:
Usually ships within three business days
Shipping:
$60.00 (Fixed Shipping Cost)
Condition:
New
Brand:
UXP
No. of Processors:
8
Form Factor:
2U
Memory Type:
DDR4 SDRAM
$2,846.00
PRODUCT DESCRIPTION
The Supermicro X11SPL-F is fully compatible with a wide range of Intel® Xeon processors, including the 81xx, 61xx, 51xx, 41xx, 31xx, 82xx, 62xx, 52xx, 42xx, and 32xx series, all of which feature a Socket P0-LGA 3647. With a thermal design power (TDP) of up to 165W and up to 28 cores, this processor is a powerhouse. This motherboard has the Intel PCH C621 chipset and supports speedy 6-channel, 8-DIMM DDR4 ECC RDIMM/LRDIMM memory with speeds up to 2933MHz.
The X11SPL-F motherboard has advanced technologies like Intel Virtualization Technology for Directed I/O that improves security and system reliability. It has PCI-Express 3.0 slots, SATA 3.0 ports, dual 1G Base-T LAN support, an M.2 slot (Type 2280 and 22110), and built-in PCIe storage solution enhancement via Intel VROC. It's perfect for I/O-intensive applications and video surveillance.
UXP 2U 4Node 24Bay Server
- Maximize computing potential with 2nd Gen Intel® Xeon® Scalable Processors. Single Socket LGA-3647 (Socket P) supported, with CPU TDP up to 165W
- Supports up to 2TB of DDR4-2933MHz memory in 8 DIMM slots, including 1TB Intel Optane DC Persistent Memory in memory mode (Cascade Lake Only)
- With Expansion slots: 2 PCIe 3.0 x8 (in x16), 4 PCIe 3.0 x8, 1 PCIe 3.0 x4 (in x8)
CONFIGURATION
| CPU | :E5-2600V3 |
| Memory | :DDR4 |
| Hard Drives | :Select A Configuration |
| OB NIC | :OCP Intel X540 10G TX2 Dual port RJ45 (4x total) |
Secondary Chassis/Motherboard Specs
| Motherboard | :T41S-2U |
| Backplane | :SATA |
| PCI-Expansions slots | :3 Slot |
| Front Bays | :24 Bay 2.5" |
| Caddies | :Optional |
| PSU Slots | :Dual |
| Power Supply | :2x PSU |
| Mounting | :Rail Kit Included |
| Warranty | :1 Year Seller Warranty |
OFFICIAL Quanta T41S-2U SPECIFICATIONS
| Physical Stats | Technical specification |
|---|---|
| Form factor | 2U rack mountable |
| Processor |
|
| Number Of Nodes | 4 |
| Number Of Processors Supported | 2
|
| Processor Supported | Xeon |
| 64-Bit Processing | Yes |
| Chipset | |
| Chipset Manufacturer | Intel |
| Chipset Model | C610 |
| Memory |
|
| Maximum Memory Supported | 1 TB |
| Memory Technology | DDR4 SDRAM |
| Memory Standard | DDR4-2133/PC4-17000 |
| Number Of Total Memory Slots | 16 |
| Controllers |
|
| Controller Type | Serial ATA/600 |
| RAID Supported | Yes |
| Display & Graphics | |
| Graphics Controller Manufacturer | ASPEED |
| Graphics Controller Model | AST2400 |
| Graphics Memory Capacity | 8 MB |
| Network & Communication |
|
| Ethernet Technology | No |
| I/O Expansions |
|
| Number Of Total Expansion Bays | 24 |
| Number Of Internal 2.5" Bays | 24 |
| Number Of Total Expansion Slots | 3 |
| Number Of PCI Express X8 Slots | 2 |
| Number Of PCI Express X16 Slots | 1 |
| Interfaces/Ports |
|
| Total Number Of USB Ports | 3 |
| Number Of USB 3.0 Ports | 2 |
| Number Of SATA Interfaces | 6 |
| Power Description |
|
| Input Voltage | 120 V AC 230 V AC |
| Dimensions | Height 3.4", Width 17.5", Depth 31.1", Weight (Approximate) 91.32 lb |
