Micas
M2-W6510-48V8C48 port network switch 25GbE SFP28 & 8x100GbE QSFP28
Product Code:
M2-W6510-48V8C
Availability:
Usually ships within three business days
Shipping:
$40.00 (Fixed Shipping Cost)
Condition:
Refurbished
Brand:
Micas Network
Type:
Network Switch
Model:
RA-B6510-48V8C-R
$3,448.00
PRODUCT DESCRIPTION
Introducing the M2-W6510-48V8C: a high-performance 25GbE switch designed for cloud-scale data centers, featuring powerful cache, advanced scheduling, and 48-port 25GbE SFP28 interfaces. With 8-port 100GbE QSFP28 interfaces, it's fully backward-compatible, enabling seamless migration of data center fabrics to 25Gbps and 100Gbps. The platform provides hot-pluggable 1+1 redundancy power modules and 3+1 redundancy cooling fan modules, ensuring high reliability for data centers and carrier networks.
First-class Performance
• Provides 48 × 25GbE ports and 8 × 100GbE ports
• Up to 4.0 Tbps (full duplex)
• Up to 2003.4 Mpps
Resilient Configuration
• Broadcom BCM56873 (Trident 3)
• Intel Xeon D-1527 Processor (Formerly Broadwell DE)
• System memory 8GB DRAM(up to 32GB)
• System storage ≥240GB
Data Center Oriented Design
• Typical power of under 4W per 100GbE port
• Over 94% efficient power supplies
Cloud Networking Ready
• Shared 32MB Buffer with burst absorption
• Up to 288K MAC and 168K Host entries
• Over 324K IPv4 Routes
• Over 168K IPv6 Routes
* The above table is the maximum capacity that the
switching chip can provide.
Fully-loaded Software Functions
• BGP, route policies, ARP in host routing, load balance
based on LAG/ECMP, Interface ACL, Global ACL, etc.
OFFICIAL M2-W6510-48V8C SPECIFICATIONS
| Feature | Technical specification | |
|---|---|---|
| Switch Model | M2-W6510-48V8C | |
| Ports | 48 x 25GbE SFP28+ 8x100GbE QSFP28 | |
| Max 100GbE Ports | 8 | |
| Max 50GbE Ports | 16 | |
| Max 40GbE Ports | 8 | |
| Max 25GbE Ports | Max 25GbE Ports | |
| Max 10GbE Ports | 80 | |
| Max 1GbE Ports | 48 | |
| MGMT Port | 1 | |
| Console Port | 1 | |
| USB Port | 1 | |
| Switching Capacity | 4.0Tbps | |
| Packets/Second | 2003.4Mpps | |
| CPU | Intel Xeon D-1527 | |
| System Memory | 8GB (Up to 32GB) | |
| System Storage | 240GB | |
| BMC Option | AST2520 | |
| Switch ASIC | Broadcom BCM56873 (Trident3 | |
| Packet Buffer | 32MB | |
| Temperature Alarm | Supports temperature alarm and overtemperature protection | |
| Power Supplies | 2 (1+1 redundant, hot-swappable) | |
| Fans | 4 (3+1 redundant, hot-swappable) | |
| OS | SONiC | |
| Airflow Options | Standard* and Reversed** airflow | |
| Max/Typical Power Consumption | 300W/172W | |
| Dimensions (W x D x H) | 17.40in ×22.04in ×1.7 in 442mm ×560mm ×43.1mm,1RU | |
| Weight (with all modules) | 32.41 lbs (14.7kg) | |
| * Standard: Front to rear ** Reversed: Rear to front | ||
| Network Operating System | ||
| This product supports SONiC, a leading open networking operating system. Micas Networks provides various SONiC offerings, including customization and intergration services. | ||
| Power Supply | ||
| Model | PA550II-F/R | PD800I-F |
| Input Connector | IEC 320-C14 | Three-pin DC connector |
| Output Power | 550 W | 550 W |
| Input Voltage | 100-240 VAC | 100-240 VAC |
| Typical Input Current | 7.2-3.5A | 7.2-3.5A |
| Frequency | 50-60 Hz | 50-60 Hz |
| Effciency | 94% Platinum | 94% Platinum |
| Standard Compliance | ||
| EMC Standards | FCC CFR Title 47, Part 15, Subpart B ICES-003 Issue 7, ANSI C63.4 | |
| Safety | EN 62368-1, IEC 62368-1, EN BS 62368-1 | |
| Certifications | FCC; IC; cTUVus; CE; CB; ANATEL; UKCA; VOC | |
| European Union Directives | Low Voltage Directive 2014/35/EU EMC Directive 2014/30/EU Directive 2012/19/EU Directive 2011/65/EU | |
| Environmental | ||
| Operating Temperature | 32 to 104° F (0 to 40°C) | |
| Storage Temperature | -40 to 158° F (-40 to 70°C) | |
| Operating Humidity | 10% to 90% RH（Non-condensing） | |
| Altitude (Operating) | 0-16,404.20 ft. (0-5,000 m) | |
