Dell
Dell R740xd2 2U Server 24-Bay LFF with Custom Configuration
Product Code:
617402-R740XD2-24BL-2PSU
Availability:
Usually ships within 3-5 business days
Shipping:
$99.00 (Fixed Shipping Cost)
Condition:
Refurbished
Brand:
Dell
Server Chassis/ Case:
POWEREDGE R740xd2
Motherboard:
Dell R740xd2
Type:
Server
Form Factor:
Rack-Mountable 2U
$799.00
PRODUCT DESCRIPTION
The Dell EMC PowerEdge R740xd2 maximizes growth while efficiently utilizing space in a 2U rack. Its powerful storage and performance options are designed to tackle your business's increasing demands.
- Support large datasets, including high-definition videos and extensive mailboxes, with up to 26 3.5-inch drives.
- Achieve top performance with up to two 2nd Generation Intel® Xeon® Scalable processors.
- Optimize costs with a mix of SSDs and HDDs.
- Improve speed with fast networking and support for up to 16 DIMMs of memory.
- Expand easily with up to five PCIe slots.
CONFIGURATION
| CPU | 2x Intel Silver 4210 2.40GHz 10C |
| Memory | 64GB DDR4 |
| Hard Drives | 1x M.2 Boss riser with U.2 480 GB NVMe |
| Controller |
1x H330 |
| NIC |
Dual port 10Gb Mezzanine (Broadcom 57414) |
Secondary Chassis/Motherboard Specs
| Server Chassis/ Case | PowerEdge R740xd2 |
| Motherboard | Dell R740xd2 |
| Front Bays | 24 Bay 12 + 12 3.5" w/ Brackets |
| Caddies | 24x 3.5" Caddies |
| PSU Slots | 2 |
| Power | 2 |
| Mounting | with Rail Kit |
| Inclusion | EMC ECS face plate included |
| Warranty | 90 Day Seller warranty |
OFFICIAL PowerEdge R740xd2 SPECIFICATIONS
| Features | Technical Specification |
| Processor | Up to two 2nd Generation Intel® Xeon® Scalable processors, up to 22 cores each |
| Memory | 16 DDR4 RDIMM slots, up to 2933MT/s, 1TB max Supports registered ECC DDR4 DIMMs only |
| Storage Controllers Internal Boot |
Internal Controllers: PERC H330, H730P, HBA330 External Controllers (RAID): 12Gbps SAS HBA Software RAID:S140 Boot Optimized Storage Subsystem (BOSS):HWRAID 2 x M.2 SSDs 240GB, 480GB Internal Dual SD Module1 |
| Drive Bays | Front drive bays: Up to 24 x 3.5” SAS/SATA (HDD) max 384TB, or up 16 x 3.5” SAS/SATA (HDD) plus up to 8 x 2.5” SAS/SATA (SSD)2 max 317.44TB Rear drive bays: Up to 2 x 3.5” SAS/SATA (HDD) max 32TB or up to 2 x 2.5” SAS/SATA (SSD)* max 15.36TB |
| Power Supplies |
750W Platinum
Hot plug power supplies with full redundancy option
|
| Dimensions |
Form factor: Rack (2U) Height: 86.8mm (3.4”)
|
| Embedded management | iDRAC9, iDRAC Direct |
| Bezel | Optional security bezel |
| OpenManage™ Software | OpenManage Enterprise, OpenManage Power Center, OpenManage Mobile |
| Integrations and connections |
Integrations: Connections:
|
| Tools | Dell EMC RACADM CLI, Dell EMC Repository Manager, Dell EMC System Update, Dell EMC Server Update Utility, Dell EMC Update Catalogs, iDRAC Service Module, iDRAC RESTful API with Redfish, IPMI Tool, OpenManage Server Administrator, OpenManage Storage Services |
| Security |
TPM 1.2/2.0, TCM 2.0 optional Secure Boot
|
| I&O and Ports |
Network options Rear ports: |
| Supported operating systems |
Canonical® Ubuntu® LTS Red Hat® Enterprise Linux |
| OEM-ready version available | From bezel to BIOS to packaging, your servers can look and feel as if they were designed and built by you. |
| Recommended support | Contact your UNIXSurplus representative today for more information.. |
SKU: 617402-R740XD2-24BL-2PSU
JAA 06/23/2025
Share:
PRODUCT DESCRIPTION
The Dell EMC PowerEdge R740xd2 maximizes growth while efficiently utilizing space in a 2U rack. Its powerful storage and performance options are designed to tackle your business's increasing demands.
- Support large datasets, including high-definition videos and extensive mailboxes, with up to 26 3.5-inch drives.
- Achieve top performance with up to two 2nd Generation Intel® Xeon® Scalable processors.
- Optimize costs with a mix of SSDs and HDDs.
- Improve speed with fast networking and support for up to 16 DIMMs of memory.
- Expand easily with up to five PCIe slots.
CONFIGURATION
| CPU | 2x Intel Silver 4210 2.40GHz 10C |
| Memory | 64GB DDR4 |
| Hard Drives | 1x M.2 Boss riser with U.2 480 GB NVMe |
| Controller |
1x H330 |
| NIC |
Dual port 10Gb Mezzanine (Broadcom 57414) |
Secondary Chassis/Motherboard Specs
| Server Chassis/ Case | PowerEdge R740xd2 |
| Motherboard | Dell R740xd2 |
| Front Bays | 24 Bay 12 + 12 3.5" w/ Brackets |
| Caddies | 24x 3.5" Caddies |
| PSU Slots | 2 |
| Power | 2 |
| Mounting | with Rail Kit |
| Inclusion | EMC ECS face plate included |
| Warranty | 90 Day Seller warranty |
OFFICIAL PowerEdge R740xd2 SPECIFICATIONS
| Features | Technical Specification |
| Processor | Up to two 2nd Generation Intel® Xeon® Scalable processors, up to 22 cores each |
| Memory | 16 DDR4 RDIMM slots, up to 2933MT/s, 1TB max Supports registered ECC DDR4 DIMMs only |
| Storage Controllers Internal Boot |
Internal Controllers: PERC H330, H730P, HBA330 External Controllers (RAID): 12Gbps SAS HBA Software RAID:S140 Boot Optimized Storage Subsystem (BOSS):HWRAID 2 x M.2 SSDs 240GB, 480GB Internal Dual SD Module1 |
| Drive Bays | Front drive bays: Up to 24 x 3.5” SAS/SATA (HDD) max 384TB, or up 16 x 3.5” SAS/SATA (HDD) plus up to 8 x 2.5” SAS/SATA (SSD)2 max 317.44TB Rear drive bays: Up to 2 x 3.5” SAS/SATA (HDD) max 32TB or up to 2 x 2.5” SAS/SATA (SSD)* max 15.36TB |
| Power Supplies |
750W Platinum
Hot plug power supplies with full redundancy option
|
| Dimensions |
Form factor: Rack (2U) Height: 86.8mm (3.4”)
|
| Embedded management | iDRAC9, iDRAC Direct |
| Bezel | Optional security bezel |
| OpenManage™ Software | OpenManage Enterprise, OpenManage Power Center, OpenManage Mobile |
| Integrations and connections |
Integrations: Connections:
|
| Tools | Dell EMC RACADM CLI, Dell EMC Repository Manager, Dell EMC System Update, Dell EMC Server Update Utility, Dell EMC Update Catalogs, iDRAC Service Module, iDRAC RESTful API with Redfish, IPMI Tool, OpenManage Server Administrator, OpenManage Storage Services |
| Security |
TPM 1.2/2.0, TCM 2.0 optional Secure Boot
|
| I&O and Ports |
Network options Rear ports: |
| Supported operating systems |
Canonical® Ubuntu® LTS Red Hat® Enterprise Linux |
| OEM-ready version available | From bezel to BIOS to packaging, your servers can look and feel as if they were designed and built by you. |
| Recommended support | Contact your UNIXSurplus representative today for more information.. |
SKU: 617402-R740XD2-24BL-2PSU
JAA 06/23/2025
90 Day Seller Warranty! Unless Stated Otherwise in Listing. For Extended Warranty Please Call: 877-UNIX-123
